SKU:CFG35UF-L

2.8 Ton Mini Excavator with Kubota Diesel Engine, Hydraulic Thumb, 4-Way Blade & Quick Coupler | CFG35UF-L

2.8 Ton Mini Excavator with Kubota Diesel Engine, Hydraulic Thumb, 4-Way Blade & Quick Coupler | CFG35UF-L

1 1
$29,999.00
Sold out
FREE SHIPPING, Liftgate service available for an additional fee at checkout.
Details

Free shipping within the U.S. (except Hawaii, Alaska, and Puerto Rico).

Delivery in 5 - 15 Business Days
Details

Please Allow for 2 to 3 Business Days to Process Order, 5 to 15 Business Days to Deliver. Times are for reference only. Specific delivery times will be adjusted based on inventory changes.
Payment:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa
  • Afterpay
View full details

Product Overview

The CFG35UF-L is a powerful and versatile 2.8-ton mini excavator designed for demanding applications in utility work, landscaping, road maintenance, construction, farming, and light industrial projects.

Powered by a reliable Kubota D1105 3-cylinder diesel engine, the CFG35UF-L delivers dependable power, excellent fuel efficiency, and smooth hydraulic performance. Combined with pilot-controlled joysticks and an advanced piston pump hydraulic system, it provides precise and responsive operation for a wide range of excavation and material-handling tasks.

The CFG35UF-L adds several practical features for greater versatility and attachment compatibility, including 4-way hydraulic dozer blade, reversible left/right-hand control configuration, dual auxiliary hydraulic outputs, and a quick coupler.

Whether you're digging trenches, grading, moving materials, clearing land, or switching between hydraulic attachments, the upgraded CFG35UF-L is built to give operators greater control and flexibility on the job site.

Uses 35 mm pin attachments

Dimension:

  • Operating Weight: 2.8 Ton (5600 lb)
  • Overall Length: 4,150 mm (163 in)
  • Overall Width: 1,500 mm (59 in)
  • Overall Height: 2,510 mm (99 in)
  • Track Size: 300*55*78 (W*P*L)

Working Range:

  • Max Digging Depth: 2,800 mm (110 in)
  • Max Digging Height: 4,235 mm (167 in)
  • Max Dumping height: 3,040 mm (120 in)
  • Max Reach at Ground: 4,665 mm (184 in)
  • Dozer Blade Width: 1,500 mm (59 in)
  • Dozer Blade Height: 325 mm (13 in)
  • Blade Max Lifting Height: 325 mm (12.8 in)
  • Blade Max Drop Depth: 300 mm (11.8 in)

Engine:

  • Engine Brand: Kubota
  • Fuel Type: Diesel
  • Model: D1105
  • Rated Power: 15.4 kw (20.6 HP)
  • Displacement: 1,123 cc
  • Fuel Capacity: 26 L (6.9 gal)
  • Hydraulic Flow Rate: 67.2 L/min (17.75 gal/min)
  • Hydraulic Pressure: 24.5 MPa (3,553 psi)
  • Battery: 12V, 63Ah

Features:

  • Hydraulic Thumb
  • Pilot Control
  • Enclosed Cab
  • Side Swing Boom
  • Water-Cooled Engine
  • 4-way hydraulic dozer blade
  • Quick coupler
  • Dual auxiliary hydraulic outputs
  • Reversible joystick control

Product Warranty

Product Warranty

This product stands up to extreme testing and come with a one-year warranty for machine.
